22

Getting Started

The connector types and functions are described as follows.

Connector Direction Type

Description/Function

CLK IN

Input

SMB

The CLK IN is a 50Ω, AC-coupled
external timebase input.

TRG IO

Input

Output

SMB

The TRG IO is a bidirectional port
for external digital trigger input or
output.

CH0

Input

BNC

These channels are for attaching
the analog input signals.

CH1
CH2
CH3

Table 2-1: Connector Pin Assignments
