Introduction

5

-3dB Bandwidth, typical

Input Range PXI-9816D PXI -9826D

PXI-9846D
PCI-9846D

PXI-9846W

@50 Ω and 1 MΩ impedance

±0.2 V, ±1 V 5.1 MHz

9.6 MHz

20 MHz

80 MHz (±1 V)
50 MHz (±0.2 V)

Input Range PCI-9816H PCI-9826H

PXI-9846H
PCI-9846H

---

@50 Ω and impedance
±1 V, ±5 V

5.1 MHz

9.6 MHz

20 MHz

---

@ 1 MΩ impedance
±1 V, ±5 V

90 KHz

---

Table 1-3: -3dB Bandwidth, typical
