Introduction

17

General Information

Specification

Value

Environment

Operating Environment

Ambient temperature:
0°C to +55°C for PXI version,
0°C to +50°C for PCI version
Relative humidity: 10% to 90%, non-condensing

Storage Environment

Ambient temperature: -20°C to +85°C
Relative humidity: 10% to 90%, non-condensing

Physical

PCB Dimension
(not including connectors)

PXI version: Single 3U PXI module, 100 mm by
160 mm
PCI version: Standard height, half length PCI
card, 167.64 mm by 106.68 mm

PCI Slot Width

1-slot

PCI Bus Interface
PCI Signaling

Support 3.3 V and 5 V signaling

PCI Interface

32-bit, 66 MHz

Electromagnetic Compatibility
Emission

EN 55022

Immunity

EN 55024

Typical Power Requirements

PCI/PXI-9816

PCI/PXI-9826

PCI/PXI-9846

+12 V

0.3 A

0.3 A

0.3 A

+5 V

1.4 A

1.5 A

2.0 A

+3.3 V

0.8 A

0.8 A

0.8 A

Total Power

13.2 W

13.7 W

16.2 W

Table 1-12: General Information
