Introduction

13

Figure 1-9: PXI-9846 FFT with ±1 V Input Range

0

0.2

0.4

0.6

0.8

1

1.2

1.4

1.6

1.8

2

x 10

7

-120

-100

-80

-60

-40

-20

0

Frequency (Hz)

Magn

itu

de (

dB

)

PXI-9846, +/-1V, S-Rate = 40MS/s, Input Signal = 0.998 MHz @ -1.1732 dBFs
