Bottom

Hovering over the bottom of a Live Viewer Window reveals the framerate, link speed, stream type, and stream speed of the current
Live View Window.

The icon in the far right of the bottom Edge Control displays an icon for the mode of the current Live View Window:

Live View

Indicates the current footage is a Live feed.

Playback - Paused

Indicates the current footage is Playback and is actively playing. This icon will appear in upper right hand
corner of frame as bottom bar is replaced by playback controls

Playback - Playing

Indicates the current footage is Playback and is actively playing. This icon will appear in upper right hand
corner of frame as bottom bar is replaced by playback controls

When a camera is active, a small green dot will blink at the lower left of the Live Viewer Window.This gives feedback that a camera
is still active, useful when the video frame rate is less than 1 frame per second.

6.2.2 Live Viewer Window Right Click Menu

Right-clicking on a Live Viewer Window provides a context menu(pictured below) with the following options

Zoom

Enables the zoom tool. Left-click to zoom in, right-click to zoom out.

Camera Control

Opens the Camera Control Pad.

Copy

Copy a still shot of the video feed to the Windows clipboard. If Show Camera Details on Copied Images is
enabled in the Live Tab of the VIGIL Client Settings, than camera information will be included on the still
image. See "Live Tab" on page 92 for info on enabling the Show Camera Details on Copied Images setting.

Stop

Stops and removes the camera from the Live Viewer window. This does not affect the recording settings.

Quad / Panorama View

Only available for 180 cameras. This toggles between displaying the 180 camera in Quad View layout or
Panoramic View Layout.

Enable On-Screen Dis-

play

Enables On-Screen display of POS/ATM data. This option will only be available if the camera is con-
figured as a Priority camera for POS/ATM on the VIGIL Server.

Digital PTZ

Enable this feature for zoom and pan control on fixed cameras. This option is available and enabled by
default for all cameras that do not have alternative camera control setup in the VIGIL Server camera set-
