13.6 Hardware Tab

The Hardware tab contains settings specific to the video rendering hardware installed on the client system.

Use VGA Hardware Accel-

eration

Enable or disable VGA Hardware Acceleration.

Monitor CPU Usage

Enable or disable the CPU Usage bar at the bottom of the main window.

COM Ports

Opens the COM Port Settings window, where COM Port settings can be configured. Select the desired
COM Port from the drop-down menu and adjust the Baud Rate, Data Bits, Stop Bits and Parity to
match that of the connected hardware.

Keyboard Settings

Allows you to add, edit, or remove a special camera control keyboard, such as the Pelco KBD300A.

Virtual Switch Input Map-

pings

Opens the Virtual Switch Input Mappings window where you can add, edit, delete, auto map, or print
virtual switch input mappings. This feature allows you to view the mapped cameras using the VIGIL
Client Virtual Switch control pad or a KBD300 by entering the monitor number and virtual switch input
number.
