ENGLISH
32
17 NETWORK INTERFACE
The DN-V1700 is equipped with 10BASE-T and 100BASE-TX interface for connection to networks.
An FTP server is mounted for file transfer. Access is possible using the FTP client (DOS prompt) function included as standard with
Windows™ 95 and later.
The same operation as serial remote is possible using the FTP “SITE” command.
✽ These operating instructions only include a general description of network control.
For details, consult your store of purchase.
2 Specifications
Protocol: TCP/IP
Mounted protocols: TCP, UDP, IP, ARP, and ICMP (in part)
Connection:
Automatic selection of 10BASE-T/100BASE-TX
Connector type: RJ-45
2 Pin layout
1
2
3
4
5
6
7
8
Pin no.
Transmission data (+)
Transmission data (_)
Reception data (+)
_
_
Reception data (_)
_
_
TXD +
TXD _
RXD +
_
_
RXD _
_
_
Signal name Name
2 Main unit settings
Network-related settings (IP address, subnet mask, etc.) are made using the serial interface commands. The default values for the
different settings are shown below.
Gateway address
Subnet mask
IP address
0.0.0.0
255.255.255.0
192.168.0.1
2 FTP server
Settings related to the FTP server (ID, password, etc.) are made using the serial interface commands. The default values for the
different settings are shown below.
Log-in ID
Password
4 to 10 letters and numbers.
No distinction between capital and small letters.
Limitations
user
noned
Default
