5 preparations – Denon DN-V1700 User Manual
Page 12
ENGLISH
12
2 Checking the accessories
Check that all the accessories are included, referring to the
section “Accessories”.
2 Mounting on the rack
The DN-V1700 uses a rack-mount chassis (1U).
Use the included rack mount fittings as shown below to
mount the DN-V1700 on a 1U type rack mount rack.
NOTE:
When mounting the DN-V1700 on the rack, be sure to use
guide rails or shelf boards, etc., on the rack side to prevent
weight from being applied to the front of the DN-V1700.
The weight of the DN-V1700 cannot be supported only
with the fittings.
Also take sufficient considerations for the installation
environment, for example with respect to heat from other
devices (use forced ventilation, etc.).
2 Mounting the feet
Set the feet in the holes in the bottom of the set and push them at the center to insert them fully.
✽ The feet are press-fitted into the set, so they cannot be removed once mounted.
5 PREPARATIONS
