ENGLISH
28
• List of other commands
(a: Issuing in stop mode, b: Issuing during file playback, c: Issuing in still and pause modes,
d: Issuing during script playback, e: Issuing as FTP “SITE” command)
Command name Command
54 Player status confirmation ?S
Function
Player status confirmation
e
C
d
C
c
C
b
C
a
C
55 Drive test nTE Check of playback medium speed C
56 HDD suspend setting nHS HDD suspend setting C
57 Network communications mode setting nHD Switch between full duplex and half duplex C
58 Log output nLW Output log to file C C
NOTE:
When accessing an FTP server with LAN connections, be sure to disconnect from the FTP server before executing the “FU” and
“RB” serial commands. When these commands are executed, the connection is terminated forcibly, so the LAN controller does
not recognize that the FTP server connection has been terminated, possibly resulting in a control error.
15 PARALLEL REMOTE CONTROL TERMINAL
An external controller can be connected to the DN-V1700 for parallel remote control.
2 Specifications
Connector type: D-sub female 15 pins
Pin layout
q
Pin
no.
*1
Shift
Selects 6th file in sorting order
Normal
Selects 1st file in sorting order
Description of pin
search 1/6
Name Modes other than script mode
Input
Input/
Output
Negative
Logic
TTL
Level
*2
KEY 1
Script
mode
w Selects 7th file in sorting order Selects 2nd file in sorting order search 2/7 Input Negative TTL KEY 2
e Selects 8th file in sorting order Selects 3rd file in sorting order search 3/8 Input Negative TTL KEY 3
r Selects 9th file in sorting order Selects 4th file in sorting order search 4/9 Input Negative TTL KEY 4
t Selects 10th file in sorting order Selects 5th file in sorting order search 5/10 Input Negative TTL KEY 5
y Switches current directory Switches current directory select Input Negative TTL KEY 6
7 Press while operating keys q to y, !1 and !2 to switch their function. shift Input Negative TTL
8 Starts playback of the current file play Input Negative TTL
9 GND
Power
supply
_ _
10 Stops file playback stop Input Negative TTL *3
!1 Turns the repeat mode on and off Skips in the sorting order 9/repeat Input Negative TTL KEY 7
!2 Turns the single mode on and off Skips in the reverse order 8/single Input Negative TTL KEY 8
13 Programmable output 1 AUX1 Output Negative TTL *4
14 Programmable output 2 AUX2 Output Negative TTL *4
15 Outputs +5V for driving an external device (NOTE 1) +5V
Power
supply
_ _
*1) Circled numbers: The function of the key changes when the key is pressed while pressing the shift button.
*2) TTL level (pull-up resistor included)
*3) Press and hold in the stop button (for at least 2 seconds) to stop script playback.
*4) Maximum output current at low level: 64 mA.
(NOTE 1): Make sure the power consumption of the external device supplied by this pin is 200 mA or less.
