E-Class 23
4.4.2 Menu Items and Values
The table below details the Printer Setup Menu List items with a brief
description of the item’s function, and the possible values.
1) MEDIA TYPE
Sets printing for direct thermal (no
ribbon) or thermal transfer (ribbon)
media.
Possible Values:
* DIRECT THERMAL
THERMAL TRANSFER
2) SENSOR TYPE
Selects the sensor type used to detect the
media’s Top Of Form (TOF) mark.
Possible Values:
* EDGE: gap / notch TOF marks
REFL (Reflective): black marks
CONT (Continuous): no TOF marks
3) PRESENT SENSOR
Enables/Disables the optional
Present Sensor feature.
Possible Values:
* NO
YES
4) CUTTER EQUIPPED
Enables/Disables the optional Media
Cutter feature.
Possible Values:
* NO
YES
5) SOP ADJUST
Sets the start of print (SOP) location,
relative to the top of form.
Possible Values:
Range: 0 – 255; default = *128
(0 = close to edge; 255 = farthest
from edge)
6) PRESENT ADJUST
Specifies an additional amount to feed
the label after printing.
Possible Values:
Range: 0 – 255; default = *128
(0 = close to edge; 255 = farthest from
edge)
7) BAUD RATE
Sets the serial port baud rate. (Must
match the host setting).
Possible Values:
600 to 38.4k; default = *9600 BPS
8) DATA BITS
Sets the serial data word length (Must
match the host setting).
Possible Values:
* 8
7
