E-Class 17
3.5 Flash Memory Expansion
The printer can be equipped with the optional Flash Memory Expansion.
This additional memory can be used to store label formats and fonts (for
font downloading instructions, see Section 5.8).
To install the Flash Memory Expansion, proceed as follows:
1. Turn the power off and
unplug the printer. Remove
any installed media from
the printer.
2. Using a coin, flathead
screwdriver, or similar
object, insert it into the
Slot on the underside of the
printer and gently pry the
Expansion Cover from the
printer.
3. With its connector facing
down, as shown, gently
insert the Flash Memory
Expansion Assembly into
the Expansion Bay until the
assembly is firmly seated.
4. Plug in and turn on the
printer.
;
Note: When using a blank expansion module for the first time, the printer
will automatically format it upon power-up; this initial format can
take up to one minute to perform.
