22
E-Class
;
Note:
When adjusting CONT FORM LENGTH, LABEL WIDTH, or ALIGN
LENGTH, momentarily pressing F1 or F2 will change the value by 1;
and, holding either button down until the Fault light flashes will
change the value by ten for each flash.
4.4.1 Printer Setup Menu List
The Printer Setup Menu List label, shown below, contains the printer’s
current values for each menu item that can be modified via the front panel
(See Section 4.4.2 for a detailed item description.)
The Menu Item Numbers correspond to the item’s position in the Menu
List for selection when pressing the
button during the Printer Setup
Procedure (see Section 4.4). For example to “Direct Select” the BAUD
RATE Menu Item press and hold the
button for 7 flashes of the
FAULT Light or for the TOF GAIN item hold
for 12 flashes, etc.
Menu
Items
Values
1)
DIRECT
= MEDIA TYPE
2)
EDGE
= SENSOR TYPE
3)
NO
= PRESENT SENSOR
4)
NO
= CUTTER EQUIPPED
5)
127
= SOP ADJUST, 0.005 in.
6)
127
= PRESENT ADJUST, 0.005 in.
7)
9600
= BAUD RATE, bps
8)
8
= DATA BITS
9)
STD
= CONTROL CODES
10)
100
= CONT FORM LENGTH, 0.01 in.
11)
3
= OOS MAXVOLT, 0.1 Volts
12)
12
= TOF GAIN
13)
10
= TOF DELTA, 0.1 Volts
14)
0
= TOF LOW, 0.1 Volts
15)
416
= LABEL WIDTH, 0.01 in.
16)
64
= SCALABLE FONT, 4KB
17)
64
= INTERNAL MODULE, 4KB
18)
NO
= LABEL ALIGNMENT
19)
100
= ALIGNMENT LENGTH, 0.01 in.
20)
HOST
= STOP LOCATION
21)
DPL
= INPUT MODE
22)
10
= HEAT
Menu Item
Numbers
;
Note:
When using narrow media, the ‘Menu Items’ column may be
truncated.
