WIRING --------------
I Terminal block layout
VY-EM
Trunk line
to VY-RVUs
6P connector
Impedance-matching
connector
• For
wiring to VY
EM entrance panels
• For wiring to residential VY-RVU's
DAI
, DA2
:
Video signal
RA1 , RA2
:
Video signal
DB1
, DB2
:
Video signal
RL+ , RL-
:
Door release control
DL+
, DL-
:
Door release control
R+ , R-
:
Power supply
(for 2-3 VY-EM's)
1 - 10
:
Individual calling,
-1-
, - :
Power supply (DC24V)
separately sheathed
X
, XE
system control
(for 2-3 VY-EM's)
EL
, EL
Door release connection
★ VY-10U add-on panel has the same terminal block,
b
, be
lllumination/light control
allowing to run another trunk cable.
Laying out the system
• Cable
Use twisted pair cable 1.0-1.2mm dia., 18 - 16AWG for trunkage line. If it contains extra pairs,
those must be terminated with a 120 Q resistor at both ends. As to individual call wires, use the
same but separately jacketed twisted pair cable, in which unused pairs may remain unterminated
- 4 -
