8 SPECIFICATIONS
VY-EM
* Power source
* Current consumption: 24V DC. Install a PS-24N power supply at each VY-EM.
VY-EM 2nd or 3rd VY VY-10U
Max. 1.4A 0.19A 0.075A
Standby 0.15A 0.15A OA
Station capacity
Camera unit
Scanning iine
Type of monitor
Calling
Communication
Door release system
Wiring & distance
1-3 YY-EM entrance call stations
1-3 VY-10U add-on panels, 10-cali
5 - 4 0 MY-1CD and/or MY-2CD residential monitors
CCD camera, with infrared LEDs
525 lines
MY-1CD or MY-2CD w/PanTilt pad
Electronic chime, 4 or 2-tone (from resid. door)
Single-channel, non-open communication
VY-EM has EL,EL dry-contact closure for door strike
(Capacity: Max. AC 24V, 50mA. Max. DC 24V, 250mA).
Activation by key-mark button on communicating MY monitor
Use twisted pair cable for trunk
1.0mm 18AWG 1.2mm 16AWG
VY-EM to residence area (VY-RVU‘s) 3 pairs + 1 / resid. 80 m 260' 100m 330'
Between VY-EM's 3 pairs + 1 / resid. Within the specified distance
VY-RVU to MY-1CD or MY-2CD 6 cond. (parallei) 20m 65' 25m 80'
★ See pages 5 ~ 11 wiring section for each system configuration.
Dimensions (H x W x D) & weight
★ The distance VY-RVU to monitor is doubled
with reinforced wires on +, -.
VY-5EM, VY-10EM 280 X 290 X 90.2 (mm).
11" x11-1/2" X 3-3/4".
62 recessed.
2-1/2" recessed 2.0Kg. (4.41 lbs.)
VY-10U 280 X 140x90.2 (mm).
1 1 " x 5-1/2” X 3-3/4".
62 recessed.
2-1/2" recessed 0.8Kg.(1.76 lbs.)
VY-RVU 140 X 74 X 42 (mm).
5-1/2" x3" X 1-1/2".
0.25Kg.(0.60 lbs.)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
Interference to radio communications. However, there is no guarantee that interference will not occur In a particular installation. If this
equipment does cause harmful inteference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna. • Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected. • Increase the separation between the equipment and receiver. • Consult the dealer or an experienced radio/TV technician
for help.
-t-
-s-
•i*
WARRANTY
Aiphone warrants its products to be free from defects of material and workmanship under normal use and service for a period of two
years after delivery to the ultimate user and will repair free of charge or replace at no charge, should it become defective upon which
examination shall disclose to be defective and under warranty. Aiphone reserves unto itself the sole right to make the final decision
whether there is a defect in materials and/or workmanship; and whether or not the product is within the warranty.
This warranty shall not apply to any Aiphone product which has been subject to misuse, neglect, accident, or to use in violation of
instructions furnished, nor extended to units which have been repaired or altered outside of the factory. This warranty does not cover
batteries or damage caused by batteries used in connection with the product.
This warranty covers bench repairs only, and any repairs must be made at the shop or place designated in writing by Aiphone.
Aiphone will not be responsible for any costs incurred involving on site service calls.
•i*
•i*
•i*
•f*
-i*
Aiphone Co., Ltd., Nagoya, Japan
Aiphone Corporation, Bellevue, WA, USA
VY-EM-I(E) 0595J
-16-
