Remove from bag of screws
and save for
the
last step
O
T
T
T
65103
#8-32 Hex Nut (188)
65900A
#1
0Bx1/2"
Black Screw (4)
(Packed with Screws)
65923
#8-32x3/8" Bolt (188)
65004
#8Ax5/1S" Screw (438)
66045
Handle (2)
66646
Washer (453)
(12 sheets of 40)
65109
#8-32 Acorn Nut (4)
(Packed with Screws)
67468
Peak Cap (2)
(Arrow Logo)
Hi'
k
66242
Door Slide (4)
66382
Lower Door Guide (4)
66183
Roof Trim Cap
(2 right & 2 left)
67545 21’
WeatherStripping(l)
11
