Anchoring Down The Building
It is important that the entire floor frame be anchored after the building is erected.
Below are recommended ways of anchoring.
Arrow
Anchoring Kit:
(Model No. AK4 or60298)
Recommended for use with
any
suggested base.
Contains:
4 Anchors with Cable, Clamps and
installation instruction.
Anchoring into
Wood/Post:
Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
holes provided
in
the frames for proper anchoring.
Arrow Anchoring Kit:
(Model No. AK100 or68383)
Recommended for use with the
concrete
foundation.
Contains:
Cornergussets, perimeter clips, hardware,
1/4" masonary drill bit and installation instruction.
Anchoring into Concrete:
1. For poured concrete slab or footing or patio blocks:
Use 1/4"
X
2" Lag Screws.
2. For Anchor Post of Concrete poured after building is
erected: Use 1/4" x 6" Lag Screws.
10
