Section 8 Device Message Details
: SOURce : TELecom ; EQUAlizer
Command type
Parameter
Function
Example of use
Sequential command
OFF or 0........Equalizer OFF
ON or 1......... Equalizer ON
Sets ON/OFF of the Jitter Setting Equalizer.
Sets the Jitter Setting Equalizer ON.
> : SOURce : TELecom : EQUAlizer ON
: SOURce : TELecom ; EQUAlizer?
Command type
Response
Function
Restriction
Example of use
Sequential command
0 ....................Equalizer OFF
1 ................... Equalizer ON
Makes a query of the setting status of the Jitter Setting Equalizer.
None
> : SOURce : TELecom : EQUAlizer?
<
1
Command type
Sequential command
Parameter
INTemal.................... Internal
LOCK 2MHB........... 2 MHz
(Balanced)
LOCK 2MHU .......... 2 MHz
(Unbalanced)
LOCK 2MBB........... 2 Mbit/s
(Balanced)
LOCK 2MBU........... 2 Mbit/s
(Unbalanced)
LOCK 15MH............ 1.5 MHz
(Unbalanced)
LOCK 15MB ........... 1.5 Mbit/s
(Balanced)
EXTemal................... External
LOCK lOM............... Lock lOM
(Balanced)
Function
Sets the clock source of the transmission signal.
Example of use
Sets the clock source of the transmission signal to internal.
> : SOURce : TELecom : CLOCk : SOURce INTemal
8-10
