8.3 Device-Specific Commands
8.3
Device-Specific Commands
The following section provides details of the device-specific commands.
As the command descriptions are classified by the subsystem, see the Appendix D correspondence between commands
and screens for more information on the correspondence with screens.
Incidentally, the device-specific commands supported by this device are sequential commands with some exceptions
An explanation is given for commands other than sequential commands every time they come up.
When a set value by a program command causes set values for other items to become unacceptable, they will be changed
to allowed values.
Moreover, the measurement starts again when settings are modified during measurement.
See the details of the operation method in this operation manual for conditions to change set values for other items and to
execute restart.
The following section shows examples of descriptions of commands.
When a restriction on command use exists, an item called the restriction is added to the example below.
Program command
Parameter type (SCPI, device-specific)
Parameter type (IEEE488.2, SCPI)
/ /
: SENS : TEL : RANG
Parameter
f
UI1 Jitter receiving range 1 Ul
1 UI4 Jitter receiving range 4 Ul
Function
Selects the range of jitter reception.
Example of use
Sets the range of jitter reception at Ul 4.
> : SENS : TEL: RANG UI4
____________ h_____________________________________________
Parameter details Example of command use
The right angled blacket ( > )
at the header shows that the
segment is a Program mes
sage and left angled blacket
( < ) shows it is a Response.
8-5
