Section 8 Device Message Details
8.3.5 CALCulate Subsystem
The CALCulate subsystem performs the performance measurement setting and measured result display.
: CALCulate
; DATA^
: CALCulate : DATA?
Command type
Sequential command
Parameter
Response
See the Table 8-1 for
Function
Reads the measured results.
Example of use
> : CALCulate : DATA? "CURRent : JAMPlitude : PTPeak"
< 1.00
Table 8-1 String
Item
Response Format
Jitter manual measurement
CURRent
Peak to Peak
"[CLiRRent:] JAMPlitude : PTPeak"
Form 6
4-Peak
"[CURRent:! JAMPlitude : PPEak"
Form 6
-Peak
"[CURRent:] JAMPlitude : MPEak"
Form 6
RMS
"[CURRent:] JAMPlitude : RMS"
Form 6
LAST
Peak to Peak
"LAST : JAMPlitude : FfPeak"
Form 6
-rPeak
"LAST : JAMPlitude : PPEak"
Form 6
-Peak
"LAST : JAMPlitude : MPEak"
Form 6
RMS
"LAST : JAMPlitude : RMS"
Form 6
8-24
