Section 2 GPIB Interface
2.1 GPIB Interface Functions
This device only functions as a device and does not function as a controller. Accordingly, the GPIB interface has the
following functions.
Table 2-1 GPIB Interface Functions
Cord
Interface Function
IEEE488.2 Standards
SHI
All the source handshake functions is available.
Incorporation of all the functions as the standard features
AHl
All the acceptor handshake functions is available.
Incorporation of all the functions as the standard features
T5
Basic talker functions is available.
Serial port function is available.
Talk only mode function is available.
Talker cancellation function is by MLA available.
The device shall incorporate one of the following sub
sets: T5, T6, TE5 or TE6.
L4
Basic listener functions is available.
No listen only mode function is available.
Listener cancellation function is by MTA available.
The device shall incorporate one of the following sub
sets: L3, L4, LE3 or LE4.
SRI
All the service request functions is available.
Incorporation of all the functions as the standard features
RLl
All the remote and local functions is available.
RLO (no functions) or RLl (all functions)
PPO
No parallel port function is available.
PPO (no functions) or PPl (all functions)
DCl
All the device clear functions is available.
Incorporation of all the functions as the standard features
DTI
All the device trigger functions is available.
DTO (no functions) or DTI (all functions)
CO
No system controller functions is available.
CO (no functions), C4 and C5, or one of the following
sub-sets: C7, C9 or C11.
2-2
