Physiccil data
19EB
UNISHELL
SIZE*
RIGGING
WEIGHT
(lb) ~| (k¿)
OPERATING
WEIGHT
OPERATING
CHARGE
R 12
(lb) (kg) (lb) i (kg) (lb)
71 19,175 1 8,698 19,975 9,061 2000 ; 907 1784
72 19,325 j 8,766 20,175 9,151 2000 i 907 1784
73 20,675 1 9,378 21,625 9,809 2180 989 1945
75 21,325 1 9,673 22,350 10,138 2180 i 989 1945
76 22,050 i 10,002 23,150 10,501 2370 ; 1075 2114
77 22,525 j 10,217 23,675 10.739 2370 ; 1075 2114
81 (a) 26,800 Í 12,156 28,375 12,871 2600 i 1179 2319
81 (b) 28,300 I 12,837 29,875 13,551 2600 i 1179 2319
82 (a) 27,125 1 1Z304 28,850 13,086 2650 i 1202 2364
82 (b) 28,625 1 12,984 30,350 13,767 2650 ; 1202 2364
83 (a) 27,950 j 12,678 29,850 13.540 2700 : 1225 2408
83 (b) 29,450 i 13.358 31,350 14.220 2700 i 1225 2408
85 (a) 29,950 i 13,585 32,040 14,533 3000 j 1361 2676
85 (b) 31,450 i 14,265 33,550 15,218 3000 1 1361 2676
87(a) 31,300 i 14,197 33,600 15,241 3100 ! 1406 2765
8/(b) 32,800 j 14,878 35,100 15,921 3100 i 1406 2765
89 (a) 34,925 i 15.842 37,465 16,994 3500
I 1588 3122
89 (b) 36,425 i 16,522 38,975 17,679 3500 j 1588 3122
i 1416
1416
*(a) — with 11 thru 49 size compressor
(b) — with 51 thru 89 size compressor
t
Electrical data
200 V 230 V 380 V 460 V 575 V 2400 V 4160 V 6900 V
MTR
MAX 3.21 FLA/Kw 2 79 FLA/Kw 1.69 FLA/Kw 1.39 FLA/Kw 1 12 FLA/Kw
MTR
MAX 270 FLA/Kw 156 FLA/Kw .094 FLA/Kw
KW
LRA LRA LRA LRA LRA LRA LRA LRA LRA LRA
KW
LRA LRA LRA
Star Delta Star Delta Star Delta Star Delta Star Delta
DB 363 2032 6351 1767 5522 1069 3342 883 2761 707 2209 DB 344 442 255 __
DC 388 2032 6351 1767 5522 1069 3342 883 2761 707 2209 DC 369 468 271
DD 418 2217 6929 1928 6024 1167 3646 964 3012 771 2410 DD 398 505 292 176
DE 443 2494 7795 2169 6777 1312 4101 1084 3388 867 2711 DE 421 534 308 186
DF 478 2494 7795 2169 6777 1312 4101 1084 3388 867 2711 DF 453 576 333 200
DG 523 — — - - 1458 4557 1205 3765 964 3012 DG 497 630 364 219
DH 561 — — — - 1410 4405 1164 3639 932 2912 DH 533 678 392 236
DJ 597 — — - — 1507 4709 1245 3890 996 3112 DJ 568 722 417 251
DK 639 — — — — 1847 5772 1526 4769 1221 3815 DK 609 774 447 269
DL 692 — — — 1993 6228 1647 5145 1317 4116 DL 659 837 483 291
DM 746 _ — - — 2139 6684 1767 5522 1414 4418 DM 709 900 519 313
DN 807 — — — — 2139 6684 1767 5522 1414 4418 DN 770 1007 618 336
DP 875 — — — — 2139 6684 1767 5522 1414 4418 DP 835 1060 613 370
DQ 875 1110 644 388
FLA — Full Load Amps
KW — Compressor Power Input (kilowatts)
LRA — Locked Rotor Amps
MTR — Motor NOTE; Overload Trip Amps = FLA x 1 08
