Appendices ~ Appendix E: Serial Commands 62
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
PEVNT
This command programs or returns the program of the GPIO
status pins from the serial port. The command line follows the
same format as shown in the PCMD example (previous page).
[DEVICE] PEVNT
Explanation
LOCATION=1 Status pin 2 active
LOCATION=2 Status pin 2 inactive
LOCATION=3 Status pin 4 active
LOCATION=4 Status pin 4 inactive
LOCATION=5 Status pin 6 active
LOCATION=6 Status pin 6 inactive
LOCATION=7 Status pin 8 active
LOCATION=8 Status pin 8 inactive
LOCATION=9 Status pin 10 active
LOCATION=10 Status pin 10 inactive
LOCATION=11 Status pin 12 active
LOCATION=12 Status pin 12 inactive
LOCATION=13 Status pin 14 active
LOCATION=14 Status pin 14 inactive
LOCATION=15 Status pin 16 active
LOCATION=16 Status pin 16 inactive
EVENT=String Pin will execute string
when actuated
EVENT=Null Parameter to return the
current programming for the
pin
EVENT=Clear Parameter to clear current
programming (do nothing
state)
EVENT LIST: AA, AD, AGC, CHAIRO, EQ, GAIN, GMODE, LFP,
MUTE, PRESET, TE
Return Values
The command will return the updated condition of the pin in the
same format as the command. If the command did not alter the
state, the command returns the current event for which the pin is
programmed.
Preset Command Note:
PRESET has two status
parameters which can be set
in a PEVNT command line: preset and
NOT preset. To indicate NOT preset, add
“!” to the end of the string. For
example, this could be used to show
when PRESET 1 occurs and then shut
off if any other preset is selected. You
would enter PRESET 1 in the active
location and PRESET 1! in the inactive
location for the desired pin.
✍
