Connectivity Module Welcome ii
Modbus is a registered trademark of Gould Inc.
Who Should Use this Installation Manual
This Installation Manual for the Connectivity Module should be used to
assist individuals who will:
• install the Connectivity Module (mount and wire)
• configure the Connectivity Module
• enter in information about your Automatic Transfer Switches
(7000 & 4000 Series, Series 300, ASCO 940,962,436,434,447,448)
• use Ethernet access to monitor Connectivity Module (connected devices)
Prerequisites A working knowledge of Windows 2000 ® , Windows NT ® , or Windows XP ®
and Windows Internet Explorer 5.0 or higher is necessary to configure the
Connectivity Module.
Important information To properly set up the software, you will need the nameplate data and other
that you will need information from all your Automatic Transfer Switches (up to 64) including:
• ATS Name (your designation for the ATS)
• ATS Location (where the ATS is located in the building)
• Voltage Rating, Ampere Rating, and number of Poles for each ATS
• Catalog No. and Serial No. of each ATS
• Type of ATS (ATS or ATS/BP [ATS with bypass-isolation switch])
• Power Manager Address (set in each Power Manager or Data Monitor)
Manuals that Catalog 5200 & 5200T Power Manager Operator’s Manual 381333-192
you may need Catalog 5220 & 5220T Power Manager Xp Operator’s Manual 381333-199
7000 & 4000 Series ATS Group 5 Controller User’s Guide 381333-126
7000 Series ATS appropriate Operator’s Manual
4000 Series ATS appropriate Operator’s Manual
Series 300 ATS appropriate Operator’s Manual
ASCO 940, 962, 436, 434,447, 448 ATS appropriate Operator’s Manual
Catalog 5110 Serial Module (Acc. 72A) Installation Manual 381333-240
Tip Ö
Communication Address form is included at the back to help you fill in
needed information on your Connectivity Modules, ATSs, & Power
Managers.
The Connectivity Module provides Ethernet-access that allows users to view
data from ASCO automatic transfer switches and Power Managers. These
precautions must be followed by all users:
WARNING
Be sure that Users to whom you give access are those persons that you
want to view information about the electrical system.
WARNING
Fill in the Communication Address Form in the back of this manual.
Be sure that you enter correct information about each Connectivity
Module, Automatic Transfer Switch, and Power Manager.
