13 | VWA 5000 Series-Installation Guide
S
TATUS
& M
ONITORING
 Once the switch is commissioned, it can be monitored by the status LED when
diagnostic mode is enabled. Once diagnostic mode is enabled, when the
magnet is placed near the switch, the LED will be off and when the magnet is
away from the switch, the LED will be on.
 The switch status can also be viewed as a present value on the network front
end.
 To enter/enable diagnostic mode:
Short the Switch for Duration of Diagnostic Mode
10+ seconds and less than 20 seconds 2 minutes
Alarms
 If a low battery alarm is detected, it will automatically be displayed at the end of
the wall controller scrolling status display.
 When an alarm message is displayed, the backlit screen on the controller will
illuminate at the same time as the message and shut off during the rest of the
status display.
Note: It is recommended to change the batteries of all the switches under a single
controller when this alarm is displayed.
Low
Batt
Indicates that one of the attached wireless switching devices (Door or window
contact) have a low battery condition.
(Only functional when used with a wireless communication adapter)
OR
A switch was removed (see page 11 under multiple switch configuration)
