6 | PIR Ready VT7300-2572 Series
M
ODEL
S
ELECTION
Part number Description
Communication
Options
VT7300F5X00-2572 Commercial Applications with Override Communication Ready
VT7300F5X00B-2572 Commercial Applications with Override BACnet MS/TP
VT7305F5X00-2572 °C/°F Hotel/Lodging Applications Communication Ready
VT7305F5X00B-2572 °C/°F Hotel/Lodging Applications BACnet MS/TP
- Controllers can be ordered with a factory installed PIR cover. Please use (5500) extension instead of the
(5000) only extension. Ex. VT7300F5500B-2572.
- Controllers ordered without a PIR cover can be retrofitted with a separate PIR accessory cover afterwards
when required
T
ERMINAL
, I
DENTIFICATION AND
F
UNCTION
1- Not used Fan H
2- Not used Fan M
3- Fan Enable/disable Fan L
4- 24 V~ Hot 24 V~ Hot
5- 24 V~ Com 24 V~ Com
6- Aux BO 5 BO 5-Aux
7- Aux BO 5 BO 5-Aux
8- Blank Blank
9- ECM Output AO 2
10-Valve Output AO 1
11- Not used Blank
12- BI #1 BI 1
13- RS RS
14- Scom Scom
15- BI #2 BI 2
16- UI #3 COS / COC /SS UI 3
