background image

21 | PIR Ready VT7300-2572 Series

Cool min
Minimum cooling setpoint limit
Default value =
54 °F ( 12 °C )

Minimum occupied & unoccupied cooling setpoint
adjustment.

Cooling setpoint range is: 54 to 100 °F ( 12.0 to 37.5 °C )

Pband
Proportional band setting
Default = 3

Adjust the proportional band used by the Terminal Equipment
Controller PI control loop.

Note that the default value of 3.0 °F ( 1.2 °C ) gives
satisfactory operation in most normal installation

cases. The use of a proportional band different than the
factory one is normally warranted in applications where the
Terminal Equipment Controller location is problematic and
leads to unwanted cycling of the unit. A typical example is a
wall mounted unit where the Terminal Equipment Controller
is installed between the return and supply air feeds and is
directly influenced by the supply air stream of the unit.

VALUE

°F SCALE

PBAND

°C SCALE

PBAND

3

3 F

1.2 C

4

4 F

1.7 C

5

5 F

2.2 C

6

6 F

2.8 C

7

7 F

3.3 C

8

8 F

3.9 C

9

9 F

5.0 C

10

10 F

5.6 C
