3 | PIR Ready VT7300-2572 Series
10. Insert each wire according to wiring diagram.
11. Gently push excess wiring back into hole (fig. 3).
12. Re-Install wiring terminals in their correct locations (fig. 3).
13. Re-install the cover (top side first) and gently push extra wire length back into
the hole in the wall.
14. Install security screw.
Features overview

System modes lock out.

System efficiency feedback.

Lockable keypads for tamper proofing. No need for Terminal Equipment Controller guards.
 PIR- ready.
 Advanced occupancy functions.

Configurable fan functions.

Auto fan speed mode.
 Auxiliary output.
 Unique configuration setup utility.

Three configurable inputs.
.
 When replacing an existing Terminal Equipment Controller, label the
wires before removal of the Terminal Equipment Controller.
 Electronic controls are static sensitive devices. Discharge yourself
properly before manipulating and installing the Terminal Equipment
Controller.
 A short circuit or wrong wiring may permanently damage the Terminal
Equipment Controller or the equipment.
 All VT7000 series Terminal Equipment Controllers are designed for use
as operating controls only and are not safety devices. These instruments
have undergone rigorous tests and verification prior to shipping to ensure
proper and reliable operation in the field. Whenever a control failure
could lead to personal injury and or loss of property, it becomes the
responsibility of the user / installer / electrical system designer to
incorporate safety devices (such as relays, flow switch, thermal
protections, etc…) and or an alarm system to protect the entire system
against such catastrophic failures. Tampering with the devices or
unintended application of the devices will result in a void of warranty.
