30 | PIR Ready VT7300 Series-Installation Guide
aux cont
Auxiliary contact
function & configuration
Default value = 0 Not
Used 0 Aux contact function used for reheat
IF SEQUENCE IS SET TO REHEAT THROUGH NETWORK
OR LOCAL, Ignore this parameter.
The output will directly follow the occupancy of the
Terminal Equipment Controller
1 Auxiliary NO, Occ or St-By = Contact Closed / Unoccupied
= Contact Opened
2 Auxiliary NC, Occ or St-By = Contact Opened /
Unoccupied = Contact Closed
Output to follow directly main occupancy and Fan on
command
Typically used for 2 position fresh air damper applications.
3 Auxiliary NO, Occ or St-By & Fan On = Contact Closed /
Unoccupied & Fan On or Off = Contact Opened
4 Auxiliary NC, Occ or St-By & Fan On = Contact Opened /
Unoccupied & Fan On or Off = Contact Closed
Output to follow secondary network occupancy
command
5 Auxiliary On/Off Control through auxiliary network
command. The output can be commanded through the
network for any required auxiliary functions through a
separate & dedicated network variable.
Auto Fan
Auto Fan Function
Default value: AS
Auto Speed Fan Mode operation for Fan Sequences 2 and 3
AS = Auto Speed during occupied periods. Fan is always on
during occupied periods.
AS AD = Auto Speed / Auto Demand during occupied
periods.
FL time
For floating models
VT73xxC5x00(x) only
Default value: 1.5
minutes
Floating actuator timing
Maximum stroke time of floating valve actuator.
Range is: 0.5 to 9.0 minutes in 0.5 minutes increment
cph
On/Off devices cycles
per hour
For On/Off models &
sequences
VT73xxC5x00(x) only
Default value = 4 C.P.H.
Will set the maximum number cycles per hour under normal
control operation. It represents the maximum number of
cycles that the equipment will turn ON and OFF in one hour.
Note that a higher C.P.H will represent a higher accuracy of
control at the expense of wearing mechanical components
faster.
Range is: 3, 4, 5, 6,7 & 8 C.P.H.
RA/DA
For Analog models
VT73xxF5x00(x) only
Default value: DA
signal
Reverse acting or Direct acting signal for Analog output
signals
DA = Direct acting, 0 to 100 % = 0 to 10 VDC
RA = Reverse acting, 0 to 100 % = 10 to 0 VDC
