17 | PIR Ready VT7300 Series-Installation Guide
Single occupied setpoints adjustment
(Local occupied setpoint adjustment when “Stp Func” = Attch Stp )
Unoccupied and stand-by setpoints adjustments
Setting of the stand-by and unoccupied setpoints is done through the network or through
configuration setup only.
Mode button menu sequence
Modes presented to the user are dependent on the sequence of operation selected.
Default mode is shown in bold when sequence of operation parameter is changed.
The available mode can only be changed through the network since there is no local
mode access
Sequence of operations
SEQUENCE SELECTED MODE MENU
0 = Cooling Only Off - Cool
1 = Heating Only Off - Heat
2 = Cooling With Electric Reheat Off
– Auto – Heat – Cool
3 = Heating With Electric Reheat Off - Heat
4 = Cooling and Heating ( 2 modulating outputs )
Off – Auto – Heat – Cool
5 = Cooling / Heating ( 2 modulating outputs) with
reheat Off – Auto – Heat – Cool
COOLING
MODE
HEATING MODE
OFF
MODE
AUTO MODE

Setpoint presented to user is
the setpoint from the last action
taken by the Terminal
Equipment Controller or the one
currently in use.
 Both heating and cooling
setpoints are changed
simultaneously while respecting
the minimum configured
deadband

If the other setpoint is the one
desired, then the MODE button
is used to toggle between the
current displayed one and the
other.
Cool XX.X
°F or °C
Heat XX.X
°F or °C
No access to setpoint
Cool XX.X °F or °C and Heat XX.X °F or
°C
Both heating & cooling setpoints change
simultaneously
Toggle from ( Heat or Cool ) using the
system MODE button
