10 | PIR Ready VT7300 Series-Installation Guide
4 pipe system cooling and heating: VT7300C5x00(x) & VT7305C5x00(x) On /
Off N.C. actuators
Mandatory

Pipe no = 4 pipes

CntrltTyp = On/Off

Fan Menu = 0 (L-M-
H)

FL time = as per
actuator

SeqOpera = 4
Cool/Heat
4 pipe system cooling and heating: VT7300C5x00(x) & VT7305C5x00(x)
Floating actuators
Mandatory

Pipe no = 4 pipes

CntrltTyp = Floating

Fan Menu = 0 (L-M-
H)

FL time = as per
actuator

SeqOpera = 4
Cool/Heat
4 pipe system cooling and heating: VT7300F5x00(x) & VT7305F5x00(x)
Analog actuators
Mandatory

Pipe no = 4 pipes

Fan Menu = 0 (L-M-
H)

RA/DA = as per
actuator

SeqOpera = 4
Cool/Heat
Normally Closed On/Off
Valve Cooling and Heating
Room Temperature
Control Thermostat
3 Speed fan
24 V~ Com
24 V~ Hot
BO2 Close
Fan-L
Fan-M
Fan-H
High
Med
Low
24 VAC fan relays
Cooling Heating
BO4 Close
Modulating Floating
Valve Cooling and Heating
Room Temperature
Control Thermostat
3 Speed fan
24 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
Fan-L
Fan-M
Fan-H
High
Med
Low
24 VAC fan relays
Cooling Heating
BO3 Open
BO4 Close
Modulating Analog
Valve Cooling and Heating
Room Temperature
Control Thermostat
3 Speed fan
24 V~ Com
24 V~ Hot
AO1
AO2
Fan-L
Fan-M
Fan-H
High
Med
Low
24 VAC fan relays
Cooling Heating
0 to 10
VDC
0 to 10
VDC
