28 | PIR Ready VT7300 Series-Installation Guide
Unocc CL
Unoccupied cooling
setpoint limit
Default value = 80 °F Unoccupied cooling setpoint range is:
54 to 100 °F ( 12.0 to 37.5 °C )
Heat max
Maximum heating
setpoint limit
Default value =
90 °F ( 32 °C )
Maximum occupied & unoccupied heating setpoint
adjustment.
Heating setpoint range is: 40 to 90 °F ( 4.5 to 32.0 °C )
Cool min
Minimum cooling setpoint
limit
Default value =
54 °F ( 12 °C )
Minimum occupied & unoccupied cooling setpoint
adjustment.
Cooling setpoint range is: 54 to 100 °F ( 12.0 to 37.5 °C )
Pband
Proportional band setting
Default = 3 Adjust the proportional band used by the Terminal
Equipment Controller PI control loop.
Note that the default value of 3.0 °F ( 1.2 °C ) gives
satisfactory operation in most normal installation
cases. The use of a proportional band different than the
factory one is normally warranted in applications where the
Terminal Equipment Controller location is problematic and
leads to unwanted cycling of the unit. A typical example is
a wall mounted unit where the Terminal Equipment
Controller is installed between the return and supply air
feeds and is directly influenced by the supply air stream of
the unit.
VALUE
°F SCALE
PBAND
°C SCALE
PBAND
3 3 F 1.2 C
4 4 F 1.7 C
5 5 F 2.2 C
6 6 F 2.8 C
7 7 F 3.3 C
8 8 F 3.9 C
9 9 F 5.0 C
10 10 F 5.6 C
