18 | PIR Ready VT7300 Series-Installation Guide
Available fan button menu sequences
FAN BUTTON
MENU
CONFIGURATION
MENU PRESENTED ARE DEPENDENT ON MODEL USED
AND SEQUENCE OF OPERATION SELECTED
DEFAULT
VALUE WHEN
SEQUENCE
TOGGLED
0 Low-Med-High 3 Speed configuration using 3 fan relays ( L-M-H ) High
1 Low-High 2 Speed configuration using 2 fan relays ( L-H ) High
2 Low-Med-
High-Auto 3 Speed configuration with Auto fan speed mode using
3 fan relays ( L-M-H-A )
High
3 Low-High-Auto 2 Speed configuration with Auto fan speed mode using
2 fan relays ( L-H-A )
High
4 On-Auto
Single Speed configuration. Auto is for Fan on demand /
On is On all the time
Auto
Auto speed fan mode is also offered in heating mode applications; it will not have any
effect on dehumidification. It will strictly be used for noise comfort issues.
Auto Speed Fan Mode operation for sequences 2 and 3 is dependent on Auto Fan
parameter. When Auto Fan is set to:
 AS (Default) = Auto Speed during occupied periods. Fan is always on during
occupied periods. Low, medium and high speeds operate on temperature offset
from set point.
 AS AD = Auto Speed / Auto Demand during occupied periods.
o Medium and high speeds operate on temperature offset from set point.
Low speed operates on demand and will shut down when no demand
is present.
I
NSTALLER
C
ONFIGURATION
P
ARAMETER
M
ENU
Configuration can be done through the network or locally at the Terminal Equipment
Controller.
 To enter configuration, press and hold the middle button (°C/°F or Override) for
8 seconds.
 If a password lockout is active, “Password” is prompted. Enter password value
using the “up” and “down” arrows and press the middle button again to gain
access to all configuration properties of the Terminal Equipment Controller.
Entering a wrong password will prevent local access to the configuration menu.
 Press the same middle button repetitively to scroll between all the available
parameters.
 Use the up and down key to change the parameter to the desired value.
 To acknowledge and save the new value, press the middle button again.
 The next parameter will now be displayed.
