Toa M-9000M2 CE-AU - Manual (Page 48)

48
7.7. Paging Volume Settings
Select "Setting Paging Volume Setting" from the menu or click the PAGE
VOL button in the main view.
Paging volume settings for all output channels are displayed in the Setting view.
[Paging Volume Settings]
Step 1. Adjust the volume level with the fader.
The level can be adjusted within the range of OFF or –70.0 to +10.0 dB in 0.5 dB units.
Step 2. Repeat Step 1 above for all channels for which the volume is set.
Adjustment function
If the "ADJUST" button on each screen is clicked, the current parameters of the 9000M2 amplifier connected
by way of the RS-232C cable are switched to the value set on this screen, allowing the set sound to be aurally
monitored.
Adjustment button
PAGE VOL button
