57
Power Source 100 – 240 V AC, 50/60 Hz (supplied from the accessory AC adapter)
Power Consumption 72 W
Input MIC 1 (Base Language): –60 dB*, 600 Ω, unbalanced, phone jack
MIC 2 (Translation Language): –60 dB*, 600 Ω, unbalanced, phone jack
AUX 1 (Base Language):
–20 dB*, 10 kΩ, unbalanced, phone jack
AUX 2 (Translation Language): –20 dB*, 10 kΩ, unbalanced, phone jack
AUX 3 (Bass and Translation Language):
–20 dB*, 10 kΩ, unbalanced, phone jack
Output LINE OUT: –20 dB*, 10 kΩ, unbalanced, phone jack
REC OUT: –20 dB*, 10 kΩ, unbalanced, phone jack, RCA pin jack
HEADPHONES: Mini jack
Number of Connectable 96 units
Chairman/Delegate Units
Number of Connectable
4 units
Infrared Transmitter/Receiver (By using 4 Distributors, up to 16 units when only the TS-905 units are used,
Units up to 12 units when only the TS-907 units are used or when both models are
mixed.)
Infrared Transmitter/Receiver 4 BNC jacks
I/O Terminal
External Control Terminal
D-sub connector (9 P, male)
LED Indicator Voting result indicators 1 – 3 (7-segment LED, double-digit number),
Audio signal receiving indicators 1 – 4 CH, Data signal receiving indicator,
External control priority indicator, External control communication indicator,
Power indicator, Battery indicator (flashes when a Chairman/Delegate unit's
battery nears complete discharge)
Function Switch Simultaneous speaker No. setting switch: 1/2/4
Mic-off setting switch:
TIME OUT ON/OFF
Speech priority selector switch: A: First-in-first-out priority,
B: Last-in-first-out priority,
C: Fixed for the first unit, and last-in-first-
out for the subsequent units
Microphone Mix/Cut Switch Mix: Chairman/Delegate units + MIC 1 + AUX 1 + AUX 3
(for the Base Language) Base Language
Cut: MIC 1 + AUX 1 + AUX 3 Base Language
Microphone Mix/Cut Switch Mix: Chairman/Delegate units + MIC 2 + AUX 2 + AUX 3
(for the Translation Language) Translation Language
Cut: MIC 2 + AUX 2 + AUX 3 Translation Language
AUX 3 Mixing Select Switch Mix: AUX 3 input is relayed to the line output.
Cut: AUX 3 input is not relayed to the line output.
Operating Temperature 0°C to 40°C
Finish Panel: Surface-treated steel plate, gray metallic, paint, semi-gloss
Dimensions 359 (w) x 118.8 (h) x 179.8 (d) mm
Weight 2.8 kg
18.1. Central Unit TS-900
18. SPECIFICATIONS
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
AC adapter (Cord length: 1.8 m DC cord, and 2 m detachable AC cord) ............... 1
