14
[Right side]
HEADPHONES MAIN SUB
POWER
ON
OFF
18
HEADPHONES MAIN SUB
15 16
17
15. Monitor volume control
Adjusts the output volume of the monitor
speaker and headphone.
16. Monitor selector switch
Selects either Base Language or Translation
Language for the source to be output to the
monitor speaker and headphone.
17. Headphone jack
Connect a headphone to this jack (mini-jack).
Connecting the headphone cuts off the
output from the monitor speaker.
Note
A headphone jack is located on both the left
and right side panels.
18. Power switch
Press this switch to switch on the power.
To switch off the power, press this switch
again.
[Left side]
HEADPHONES
19
17
19. DC inlet
Connect the dedicated AD-0910 AC Adapter
to this terminal.
Note: No microphone is supplied with the TS-901 Chairman unit.
