42

13. CHAIRMAN AND DELEGATE UNIT POWER SUPPLY

Use either the optional BP-900 Lithium-Ion Battery or the AD-0910 AC Adapter for the power supply of the
Chairman and Delegate units.

13.1. BP-900 Lithium-Ion Battery

13.1.1. Inserting the lithium-ion battery

Note: A fully charged battery can be continuously used for about 10 hours.

Arrow

Lithium-ion battery BP-900

Chairman unit TS-901
or
Delegate unit TS-902
(bottom side)

1

2

Lithium-ion battery compartment

Reverse the above procedures to remove the battery.

Slide the battery in the direction
indicated by the arrow until it
stops and fits into place.

Align the battery slots (4 places) with
the corresponding tabs located on the
unit's underside, and insert the battery
into the battery compartment.
