Disassembly
2 - 20 Removing the Modem
2.Disassembly
4. Carefully lift the top case ( Figure 16e ) up and off the computer.
5. Remove screws - from the modem and disconnect cable .
6. Lift the modem ( Figure 16g ) up and off the computer.
30
31 32 33
34
30. Top Case
34. Modem
• 2 Screws
e.
f.
30
34
g.
32
31
33
34
Figure 16
Modem Removal
(cont’d)
e. Lift the top case off the
computer.
f. Remove the screws and
disconnect the cable.
g. Lift the modem off the
computer.
