Page 27
Sample Applications
151253
23
Section 5
Sample Applications
The drawings in this section show various 5499 configurations, including
“daisy-chaining”.
5.1
Notification Power Applications
Figure 5-1 Input 1 Activates All Four Outputs
Figure 5-2 Input 1 Activates NACs 1 and 2; Input 2 Activates NACs 3 and 4
5499
Local Fire Alarm
Control Panel
Local Fire Alarm
Control Panel
5499
