4-41
Cisco IOS Software Configuration Guide, Release 12.2SX
OL-13013-06
Chapter 4 Configuring Virtual Switching Systems
Configuring a VSS
R - Layer3 S - Layer2
U - in use N - not in use, no aggregation
f - failed to allocate aggregator
M - not in use, no aggregation due to minimum links not met
m - not in use, port not aggregated due to minimum links not met
u - unsuitable for bundling
w - waiting to be aggregated
Group Port-channel Protocol Ports
------+-------------+-----------+---------------------------------------------
10 Po10(RU) - Te1/5/4(P) Te1/5/5(P)
20 Po20(RU) - Te2/5/4(P) Te2/5/5(P)
Router# show switch virtual link port
VSL Link Info : Configured: 2 Operational: 1
Peer Peer Peer
Interface State MAC Switch Interface
-----------------------------------------------------------------------
Te1/5/4 operational 0013.5fcb.1480 2 Te2/5/4
Te1/5/5 link_down - - -
Last operational Current packet Last Diag Time since
Interface Failure state State Result Last Diag
-------------------------------------------------------------------------------
Te1/5/4 No failure Hello bidir Never ran 7M:51S
Te1/5/5 No failure No failure Never ran 7M:51S
Hello Tx (T4) ms Hello Rx (T5*) ms
Interface State Cfg Cur Rem Cfg Cur Rem
----------------------------------------------------------------------
Te1/5/4 operational 500 500 404 5000 5000 4916
Te1/5/5 link_down 500 - - 500000 - -
Te2/5/4 operational 500 500 404 500000 500000 499916
Te2/5/5 link_down 500 - - 500000 - -
*T5 = min_rx * multiplier
Configuring VSL QoS
The VSS automatically configures VSL ports for trust CoS, using default CoS mappings (you cannot
change the mappings on VSL ports).
For switching modules that support per-ASIC configuration, the VSL configuration applies to all ports
on the same ASIC (including any non-VSL ports).
The VSS disables the QoS commands on VSL ports (and any non-VSL ports on the same ASIC). For
example, you cannot use QoS queuing or map commands on VSL ports.
To ensure that all eight QoS receive queues are enabled for the 10-Gigabit Ethernet ports on the
supervisor engine, enter the mls qos 10g-only global configuration command.
In Cisco IOS Release 12.2(33)SXI and later releases, when the mls qos 10g-only command is entered
and only one of the two 10-Gigabit Ethernet ports on the supervisor engine is a VSL port, the non-VSL
10-Gigabit Ethernet port can be configured for QoS.
