Reznor B Parts Manuals - Manual (Page 11)

Form P-F/B (01-8-15), P/N 272436R5, Page 11
TEFC Motor Voltage AK Opt Drive AM Option Motor Pulley Blower Pulley Belt Type &
Average Length* HP AL Opt (See Key, page 10.) (See Key, page 10.) P/N Model Bore P/N Model Bore
1/4 19
AK1
1, 2 4074 1VL34 1/2 111609 AK 99 1 "A-section" 3.8 ft
3, 4 13491 1VL40 1/2 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 13491 1VL40 1/2 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 13491 1VL40 1/2 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 13491 1VL40 1/2 135200 AK 51 1 "A-section" 3.8 ft
AK2, AK3, AK5, AK6,
AK7
1, 2 13580 1VL34 5/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 "A-section" 3.8 ft
1/3 20
AK1, AK2, AK3, AK5,
AK6, AK7
1, 2 4074 1VL34 1/2 111609 AK 99 1 "A-section" 3.8 ft
3, 4 13491 1VL40 1/2 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 13491 1VL40 1/2 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 13491 1VL40 1/2 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 13491 1VL40 1/2 135200 AK 51 1 "A-section" 3.8 ft
1/2,
3/4, 1
21, 22,
23
AK1, AK2, AK3, AK5,
AK6, AK7, AK8
1, 2 13580 1VL34 5/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 "A-section" 3.8 ft
1-1/2 24
AK1, AK2, AK3, AK5,
AK6, AK7
1, 2 13580 1VL34 5/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 "A-section" 3.8 ft
AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 "A-section" 3.8 ft
2 25 AK5, AK6, AK7, AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 "A-section" 3.8 ft
3 26 AK5, AK6, AK7, AK8
9, 10, 11, 12 106748 1VL40 7/8 101414 BK130 1 "B-section" 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 202654 BK105 1 "B-section" 3.8 ft
* Assume 17 Fenner belt links per foot. One "A" belt link is P/N 201809. One "B" link is P/N 202655.
Open Motor (cont'd) Voltage AK Opt Drive AM Option Motor Pulley Blower Pulley Belt Type &
Average Length* HP AL Opt (See Key, page 10.) (See Key, page 10.) P/N Model Bore P/N Model Bore
1/2, 3/4, 1,
1 1/2
4, 5, 6, 7
AK1, AK2, AK3,
AK5, AK6, AK7
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 "A-section" 3.8 ft
1/2, 3/4 4, 5 AK8
1, 2 13580 1VL34 5/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 "A-section" 3.8 ft
1, 1-1/2 6, 7 AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 "A-section" 3.8 ft
2 8
AK1, AK2, AK3
1, 2 13580 1VL34 5/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 "A-section" 3.8 ft
AK5, AK6, AK7, AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 "A-section" 3.8 ft
3 9 AK2, AK3
9, 10, 11, 12 7962 1VL40 5/8 202652 AK124 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 202653 AK94 1 "A-section" 3.8 ft
3, 5 9, 10 AK5, AK6, AK7, AK8
9, 10, 11, 12 106748 1VL40 7/8 101414 BK130 1 "B-section" 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 202654 BK105 1 "B-section" 3.8 ft
* Assume 17 Fenner belt links per foot. One "A" belt link is P/N 201809. "B" link is P/N 202655.
