Motor Service
Factor
Power
Factor Efficiency
Contactor Reznor ®
P/N
Overload o.l. o.l. Reznor ®
P/N Type HP fla Model No. P/N volt ph GE # GE # min max
TEFC
1/3 1.2 H261 105567 208 3 1.15 79.50% CL00A310T-L 151150 RTA1-G 1.00 1.50 151187
1/3 1.2 H261 105567 240 3 1.15 79.50% CL00A310T-S 151147 RTA1-G 1.00 1.50 151187
1/3 0.6 H261 105567 480 3 1.15 79.50% CL00A310T-U 151148 RTA1-D 0.40 0.65 151184
1/2 7.2 C613 159184 120 1 1.15 - - - - - -
1/2 3.5 C613 159184 208 1 1.15 - - - - - -
1/2 3.6 C613 159184 240 1 1.15 - - - - - -
1/2 2.3 H274 16077 208 3 1 59.5 74.80% - - - - - -
1/2 2 H274 16077 240 3 1 59.5 74.80% - - - - - -
1/2 1 H274 16077 480 3 1 59.5 74.80% - - - - - -
1/2 0.7 H276 105568 575 3 1.15 76.4 77% Contact distributor or factory.
3/4 11 F353 115860 120 1 1 66 65.70% - - - - - -
3/4 5.4 F353 115860 208 1 1 66 65.70% - - - - - -
3/4 5.5 F353 115860 240 1 1 66 65.70% - - - - - -
3/4 2 H580 20371 208 3 1 73.5 81.10% - - - - - -
3/4 2.2 H580 20371 240 3 1 73.5 81.10% - - - - - -
3/4 1.1 H580 20371 480 3 1 73.5 81.10% - - - - - -
3/4 0.8 H461 105569 575 3 1.15 78.3 82% Contact distributor or factory.
1 12 159105 174993 120 1 1.15 74.3 70.60% - - - - - -
1 6.2 159105 174993 208 1 1.15 74.3 70.60% - - - - - -
1 6 159105 174993 240 1 1.15 74.3 70.60% - - - - - -
1 3.3
WEG-
00118ES3ED56 271444 208 3
1 74.4 80.20% CL00A310T-L 151150 RTA1-K 2.50 4.10 151190
1 3.4
WEG-
00118ES3ED56 271444 240 3
1 74.4 80.20% CL00A310T-S 151147 RTA1-K 2.50 4.10 151190
1 1.7
WEG-
00118ES3ED56 271444 480 3
1 74.4 80.20% CL00A310T-U 151148 RTA1-H 1.30 1.90 151188
1 1.4 H525 105570 575 3 1.15 71.6 80.40% CL00A310T-J 151146 RTA1-G 1.00 1.50 151187
1.5 16.4 311P402 94347 120 1 - - - - - -
1.5 9.5 311P402 94347 208 1 - - - - - -
1.5 8.2 311P402 94347 240 1 - - - - - -
1.5 4.3
WEG-
00158ES3ED56 271445 208 3
1 80.9 82.40% CL00A310T-L 151150 RTA1-L 4.00 6.30 151191
1.5 4.4
WEG-
00158ES3ED56 271445 240 3
1 80.9 82.40% CL00A310T-S 151147 RTA1-L 4.00 6.30 151191
1.5 2.2
WEG-
00158ES3ED56 271445 480 3
1 80.9 82.40% CL00A310T-U 151148 RTA1-J 1.90 2.70 151189
1.5 1.7 AOS T59027 105665 575 3 1.15 85.7 84% CL00A310T-J 151146 RTA1-H 1.30 1.90 151188
2 12 K200 105572 240 1 1 76.4 75.70% CL01A310T-S 151152 RTA1-P 10.00 16.00 151194
2 6.1 WEST NP0024 158165 208 3 1.15 77.5 84% CL00A310T-L 151150 RTA1-M 5.50 8.50 151192
2 5.6 WEST NP0024 158165 240 3 1.15 77.5 84% CL00A310T-S 151147 RTA1-L 4.00 6.30 151191
2 2.8 WEST NP0024 158165 480 3 1.15 77.5 84% CL00A310T-1 151275 RTA1-K 2.50 4.10 151190
2 2.2 AOS T59028 158166 575 3 1.15 77.5 84% CL00A310T-J 151146 RTA1-J 1.90 2.70 151189
3 7.7
BALDOR
EM3559T
159330 208 3 1.15 85.50% CL00A310T-L 151150 RTA1-M 5.50 8.50 151192
3 7
BALDOR
EM3559T
159330 240 3 1.15 85.50% CL00A310T-S 151147 RTA1-M 5.50 8.50 151192
3 3.5
BALDOR
EM3559T
159330 480 3 1.15 85.50% CL00A310T-1 151275 RTA1-K 2.50 4.10 151190
3 3 B-M3559T-5 111571 575 3 1.15 85.50% CL00A310T-J 151146 RTA1-K 2.50 4.10 151190
Belt Drive Components
NOTE: Pulleys require
keyseats, see Code 46,
page 8.
Key to AM Nos.
Option AM RPM Range Option AM RPM Range
2 451-500 8 751-800
3 501-550 9 801-850
4 551-600 10 851-900
5 601-650 11 901-950
6 651-700 12 951-1000
7 701-750
Key to AK Nos.
Option
AK
Voltage
Option
AK
Voltage
1 115/1 6 230/3
2 208/1 7 460/3
3 230/1 8 575/3
5 208/3
Open Motor Voltage AK Opt Drive AM Option Motor Pulley Blower Pulley Belt Type &
Average Length* HP AL Opt (See Key, above.) (See Key, above.) P/N Model Bore P/N Model Bore
1/4, 1/3 2, 3
AK1, AK2, AK3,
AK5, AK6, AK7
1, 2 4074 1VL34 1/2 111609 AK 99 1 "A-section" 3.8 ft
3, 4 13491 1VL40 1/2 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 13491 1VL40 1/2 19111 AK 84 1 "A-section" 3.8 ft
8, 9, 10, 11, 12 13491 1VL40 1/2 18797 AK 64 1 "A-section" 3.8 ft
13, 14, 15, 16, 17 13491 1VL40 1/2 135200 AK 51 1 "A-section" 3.8 ft
1/2, 3/4, 1,
1-1/2
4, 5, 6, 7
AK1, AK2, AK3,
AK5, AK6, AK7
1, 2 13580 1VL34 5/8 111609 AK 99 1 "A-section" 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 "A-section" 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 "A-section" 3.8 ft
Belt-Driven Blo wer Motors and Motor Starters (cont'd)
