Drill (4) holes per template from bottom of cabinet
Installation Instructions
444 Series Wall Pull-Outs
1
3
Note: The extra set of chrome rails
(included) are for use in a 36” or 42”
height wall cabinet for additional
shelf space. Holes are predrilled.
Center unit on
cabinet floor,
align front edge
to inside edge of
face frame.
2
Screw from underside of
cabinet into
wood slide housing.
Screws not provided.
Attach door to unit.
Note: Utilize the adjustable door
mounting brackets to ensure
mounting in thick portion of
cabinet door.
4
