Rev-A-Shelf CWTBR-Series User Manual
5 min, Installation instructions
2.75 [69.85MM]
MIN.
1.457 [37MM]
TOOLS REQUIRED:
ESTIMATED ASSEMBLY TIME:
CARE AND MAINTENANCE:
5 MIN
Clean with a damp cloth and
wipe parts dry.
PARTS LIST:
EURO SCREW
X
3
FOR 20”
SLIDE
2409 Plantside Dr.
800.626.1126 • www.rev-a-shelf.com
Installation Instructions
Before beginning assembly, installation or operation of the product make sure all parts are present
Contact customer service for replacement parts - (800) 626-1126.
I-WBB-1112
X
2
FOR
12,14,16”
X
2
NOTE: If back system hole does not match slide hole pattern, use wood
screw instead.
20” ONLY
20” ONLY
FLAT HEAD
