Proceed to 444 installation instructions.
Instructions for
Reversing 444 Wall Unit
1
2
5
The 444 Perforated Pull-Out Organizer comes from the factory with
the stainless steel perforated panel on the left side.
Follow the instructions below to switch the panel to the right side.
3
Depress the
release lever on
all three slides
and remove the unit
from the
base sub-assembly.
Remove the product
members and rotate them
180 degress,
align them with the
edge of the
unit and re-attach.
Remove AMB’s
(adjustable mounting
brackets) and attach to
opposite side of unit.
Install top chrome rails (3)
with the small rail on the
opposite side of the door.
4
