Rev-A-Shelf CSPD-6 User Manual
Acrylic dividers, Installation instructions

ACRYLIC DIVIDERS
INSTALLATION
INSTRUCTIONS
I CSPD
Insert the connectors in the desired system holes on the shelf bottom.
Repeat on the underside of the top shelf.
1
37 mm
37 mm
x2
Insert the the acrylic divider into the bottom connectors
with notches facing down.
Place the top shelf with connectors installed
on top of the acrylic dividers. Lock shelf into
position with standard cam and dowel
2
3
14”
ACRYLIC DIVIDERS
INSTALLATION
INSTRUCTIONS
I CSPD
Insert the connectors in the desired system holes on the shelf bottom.
Repeat on the underside of the top shelf.
1
37 mm
37 mm
x2
Insert the the acrylic divider into the bottom connectors
with notches facing down.
Place the top shelf with connectors installed
on top of the acrylic dividers. Lock shelf into
position with standard cam and dowel
2
3
14”
12400 EARL JONES WAY • LOUISVILLE, KY 40299 • (800) 626-1126
12400 EARL JONES WAY • LOUISVILLE, KY 40299 • (800) 626-1126
