MBOX
®
STUDIO USER MANUAL
Parameter Mapping
Summary: Single Output
Start
Size
Type
Universe
1
11
Master
1st
369 Total
Channels
12
8
Keystone
20
14
Shutter
34
42
Layer 1
76
42
Layer 2
118
42
Layer 3
160
42
Layer 4
202
42
Layer 5
244
42
Layer 6
286
42
Layer 7
328
42
Layer 8
Summary: Dual Output - Panoramic Wide
Start
Size
Type
Universe
1
11
Master
1st
369 Total
Channels
12
8
Keystone
20
14
Shutter
34
42
Layer 1
76
42
Layer 2
118
42
Layer 3
160
42
Layer 4
202
42
Layer 5
244
42
Layer 6
286
42
Layer 7
328
42
Layer 8
