Page 48
40
VL6C+ ™ SPOT LUMINAIRE USER MANUAL
The channel assigned to the rotating wheel selects the required gobo as follows:
Timing Channels
Timing channel control improves the timed moves of certain groups of parameters. Three timing channels are
provided: one for Focus (Pan and Tilt), one for color parameters and one for beam parameters. Timing channels
support time values of up to six minutes.
A timing value of zero is full speed. A time value of 100% (or 255 in DMX) causes the associated parameter(s) to follow
cue fade time (console time) rather than the timing channel.
DMX
Values
Percent
Values
Action
DMX
Values
Percent
Values
Action
156-255
Open
53-76
25
Gobo 2
129-153
55
Gobo 5
27-52
15
Gobo 1
102-128
45
Gobo 4
0-26
5
Open
77-102
35
Gobo 3
Value
Action
0 - 2
Open
3 - 5
Closed
6 - 7
Slow Random
8-10 Medium
Random
11-12
Fast Random
13-255
Where 13 is greatest interval and 255 is least interval (fastest) strobe
Channel Function
Timing Channel
Focus Time
Color Time
Beam Time
Pan (Hi Byte/Lo Byte)
Tilt (Hi Byte/Lo Byte)
Blue
Amber
Magenta
Color Wheel
Diffusion
Beam
Edge
Zoom
Rotating Gobo
Gobo Index (HiByte/LoByte)
Shutter (all 9 motors)
