30 VL6C+ ™ SPOT LUMINAIRE USER MANUAL
Lamp Douse Switch
The lamp douse switch should be used to douse the arc lamp before disconnecting the pigtail cable. This will prevent
damage to the contacts in the CPC connector, which can be caused by drawing an arc during disconnect. To douse
the lamp, press the lamp douse switch located at the yoke cross-member.
Figure 3-2: Lamp Douse Switch Location
Note: Refer to "Proper Lamp Servicing and Operation" on page 43 for correct lamp operating procedures.
Lamp Douse Switch
CPC Connector
Pigtail Cable
