VL6C+ ™ SPOT LUMINAIRE USER MANUAL 35
DMX Mode 8
Applies to Smart Repeater Plus Unit ONLY.
Table 3-4: DMX512 Mode 8 (16-bit Extended)
Port Number DMX Channel VL6C+ Luminaire
1
1 Intensity
2 Hi Byte Pan
3 Lo Byte Pan
4 Hi Byte Tilt
5 Lo Byte Tilt
6 Wheel 1
7 Wheel 2
8 Beam Iris
9 Lens (Edge)
10 Strobe
11 Zoom
12 Rotating Wheel
13 Rotation/Index
14 Focus Time
15 Color Time
16 Beam Time
17 Reset
18 --
19 --
20 --
2 21-40 --
3 41-60 --
4 61-80 --
5 81-100 --
6 101-120 --
