28 VL6C+ ™ SPOT LUMINAIRE USER MANUAL
POWER-UP PROCEDURES
Powering Up the Luminaire
When power is applied, the VL6C+ Spot Luminaire will begin a calibration sequence which moves its pan, tilt, and all
other mechanisms. After calibration, the luminaire head will either stop at its "home" position (which positions the pan
and tilt axis at mid-rotation) or move to its current DMX-defined position if DMX512 data is present. All other
mechanisms will also move to their "home" or DMX-defined positions.
CAUTION: Before applying power, be sure the luminaire is positioned so that the head and yoke can move
freely without restriction. Refer to the Installation chapter for complete setup instructions.
To power up:
Step 1. Apply power and data to Smart Repeater or Smart Repeater Plus.
Step 2. Allow luminaire to complete calibration sequence.
Step 3. The luminaire is now ready for operation. See "DMX512 Mapping" on page 32 for control parameters.
Note: Refer to "Proper Lamp Servicing and Operation" on page 43 for correct lamp operating procedures.
